進口SKD11模具鋼材 國產SKD11是什么材料 日本大同SKD11價格

SKD11是高耐磨韌性通用冷作模具鋼、高碳高鉻合金工具鋼和真空脫氣精煉鋼，鋼質純淨，具有淬透性好、淬火變形量小的良好淬硬性。該鋼經球化退火軟化處理，可加工性良好，碳化物顆粒細小均勻，無須擔心淬火開裂強化元素鉬、釩的持殊加入。
SKD11為，日立和大同鋼廠都有生產，日立產SKD11商品名為SLD（最新改良版稱作SLD-MAGIC），大同鋼廠商品名為DC11。兩者在大陸均有設廠，在業界最為知名，價格也最高。該鋼是一種在國際廣泛應用的空冷硬化冷作模具鋼。經電爐冶煉並經電渣重溶，高純淨度，韌性更好，組織均勻，具有良好的高溫強度、韌性與抗高溫疲勞效能，能承受溫度驟變。
高硬度、高耐磨共晶碳化物均勻，韌性好、不易開裂，淬火後硬度>62HRC。在525℃氮化處理時間為20h/30h/60h，氨化層深度0.25mm/0. 30mm/0. 35mm，零件表面硬度1250HV；在570℃氮化處理時間為2h，氮化層深度10~20μm，零件表面硬度950HV。
化學成分
Si矽≤0.40
Mn錳≤0.60
P磷≤0.030
S硫≤0.030
Cr鉻11.0-13.0
Mo鉬0.80-1.20
Ni鎳≤0.50
V釩0.20-0.50
Cu銅≤0.25
1、高溫強度和韌性好，耐磨性較佳，易切削；
2、SKD11是一種有很好強度、韌性及耐熱平衡性的冷模具鋼，近年來隨著各向同性產品的開發而日益向高韌性等方面發展，它可以使模具壽命更長，效能更穩定，且易於加工，熱處理變形小。
產品特點
（1）進行了真空脫氣精煉，囙此內部質量極為清潔。
（2）機械加工性良好。
（3）淬透性良好，空冷就能硬化，無需擔心淬裂。
（4）熱處理變形非常小，淬火偏差極小，最適合有精度要求的模具。
（5）耐磨性極為優秀，最適合用作鏽鋼或高硬資料的沖裁模。
（6）韌性良好。
SKD11在鋁、鋅壓鑄用模具材料方面，應用最為廣泛，此鋼含有鎢成分之耐高溫高級合金鋼，適用於熱作，鋁、鎂、鋅、銅合金壓鑄模，切槽刀，剪刀及熱鍛動作，塑膠型模，熱作鉸刀，軋刀，一般熱作鍛模，熱螺栓模，熱間各種工具等。

SKD11 is a high wear resistance and toughness general cold die steel, high carbon high chromium alloy tool steel and vacuum degassing refining steel, steel purity, with a good quenching, quenching deformation of small good quenching. The steel can be processed by ball annealing and softening, and can be processed well, fine and uniform carbide particles are not required to be worried about the quenching cracking and strengthening elements molybdenum and vanadium.
SKD11 is, Hitachi and Datong steel mills have production, Hitachi SKD11 production of SLD goods called (the latest improved version called SLD-MAGIC), Datong steel mill product name is DC11. Both in the mainland have set up factories in the industry's most famous, the price is also the highest. This steel is a kind of cold working die steel in the wide application of the world. The electric furnace smelting and the electroslag remelting, high purity, better toughness, uniform structure, has good high temperature strength, toughness and anti fatigue properties at high temperature, withstand sudden changes of temperature.
High hardness, high wear resistant eutectic carbide uniform, good toughness, not easy to crack, after quenching hardness >62HRC. In 525 C nitriding processing time for 20h/30h/60h, ammoniation layer depth 0.25mm/0. 30mm/0. 35mm, parts of the surface hardness 1250HV; at 570 C nitriding processing time for 2h, the depth of the nitrided layer 10 ~ 20 m, the surface hardness of the parts 950HV.
Chemical composition
Si silicon is less than or equal to 0.40
Manganese is less than 0.60 Mn
P = 0.030 P
Sulfur is less than 0.030 S
Cr chromium 11.0-13.0
Mo 0.80-1.20
Ni Ni = 0.50
V vanadium 0.20-0.50
Cu copper is less than or equal to 0.25
1, high temperature strength and toughness, good wear resistance, easy cutting;
2, SKD11 is a very good strength, toughness and heat balance of cold die steel, in recent years, with the development of isotropic products increasingly to the development of high tenacity, it can make the tool life is longer and more stable performance, and easy processing, heat treatment deformation is small.
Product features
(1) the vacuum degassing refining is carried out, and the quality of the interior is very clean.
(2) good mechanical processing.
(3) the quenching is good, the air cooling can be hardened, without having to worry about the quenching.
(4) the deformation of heat treatment is very small, the quenching deviation is small, and most suitable for the mould with the precision of the requirements.
(5) the wear resistance is excellent, and the most suitable for use as a rust or high hardness material punching die.
(6) toughness is good.
SKD11 in aluminum, zinc die-casting mold materials, the most widely used, the steel containing tungsten components of resistance to high alloy steel with high temperature, it is suitable to be used in hot, aluminum, magnesium, zinc, copper alloy die, cutting groove cutter, scissors and hot forging action, type of plastic mould, hot reamer, rolling knife, like a hot forging die, heat a bolt die, hot various tools and so on.
